Working principle:
This machine consists of turntable, conveyer, sticker label fixing device, coding system, bottle outlet track and electric control system.
It use conveyor for bottle feeding, servo motor drives the label to the coding system to print the preset characters. When the fiber sensor sense the bottle position, it will send label by the servo motor automatically and conduct the labeling process
Characteristic:
This labeling system is equipped with stepper driven (Taiwan technique) for allows stable torque when around-the-clock operate consistently.
Programmable logic control system integrared with user-friendly touch screen interface panel which is both versions selected of English and Chinese, as well as illustrated display for operate ef-fortless.
The machine used container-space to feeding bottles for allows stable labeling and apply thelabel on all kinds of round containers in semi-orfully wrap- Around. Optional includes hot stamping date coder to coding lot no., MFG date and expiry date, etc.
Model | KTN-250 |
Drive | Steper motor drived |
Labeling speed | 0~200PCS/MIN |
Precision | ±1mm |
Label width | 20~80mm |
Lable core | Stander 76mm |
Product size | 20~100mm |
Power | AC 220V 250W |
Weight | 200kgs |
machine size | 1500mm(L) X1100mm(W)X950mm(H) |
Spare parts for Ref:
PLC control system Chassis
Roll label device Conveyor made depends on bottle size
Printer device (optional) Turntable (optional)
1.Nomally shipping steps:
2.Our packing and shipping:
Pre-Sales Service:
* Inquiry and consulting support.
*Quickly reaction.
*Factory inspection available anytime.
After-Sales Service:
*Prompt technical support
*Engineers available to service machinery overseas
*Installation &commissioning,good training for customers.
Q1.What's your delivery method?
A1:We commonly use sea transportation, using container to deliver the goods through Shanghai Port.
Q2.What products can you provide?
A2:Our main product includes powder mixers,granulating equipments,drying equipments,capsule fillers,blister packing machines,tablet/capsule counting filling line,ampoule/vial/oral liquid filling line includes ultrasonic washing machine,sterilization oven,filling capping machine,labeling machine.
Q3. What's the payment terms?
A3:We will confirm the payment with you when quoting, like FCA, CIF or others.T/T is the main payment.
Q4.How do you ensure your product quality?
A4:We conduct inspections in every production procedure, and for finished products, we will take 100% inspection depend on international standards according to customer's requirements.
Q5:Does the machine power voltage meet buyers' factory power source?
A5: We can do it as your request.
Q6: Is it difficult to install the machine ?
A6: For standard small machines, the machines will be packed with no take apart, it comes to you to be a complete machine; you just need to connect power and compressed air to machine, then begin to operate the machine.
For large size machines, we will take the machine apart, on condition that we do our best to keep the machine easy to assembly.
You will get videos and instructions about installation of machine from us.
