Features:
1. Extremely efficient, high power, low noise, easy to maintain and has a long life span.
2. Roller heat sealing, four side sealing, high speed and multi-line packing, and with bags coming smoothly and fine, high packing efficiency.
3. Easy to adjust, precise in measurement, requires a simple procedure for pouch length adjustment without changing the mould. Functions can be regulated for longitudinal sealing, transverse sealing, filling, notch cutting, longitudinal cutting, fracture line making and transverse cutting with the advanced technology for our man-machine interface.
4. Famous servo motor driver is adopted, high-performance PLC pouch length can be setup directly at the touch screen, at the same time longitudinal sealing and transverse sealing be able to auto in-phase tracking. It saves more time and material compare with mechanical transmission, and with bag pulling smoother and even easier to adjust.
5. Accuracy in page correcting, automatic counting, and photoelectric tracking system is adopted to ensure the automatic correcting the double face printing design on packing bags, precise in counting.
6. It has reliable performance, convenient to operate and super automatic. A PLC is used for automatic controlling and frequency changer is for step-less speed adjusting.
7. Applicable to a wide using: Suitable for most of the complex film packing materials.
Applications:
UIt is suitable to pack liquid materials in the fields of pharmaceutical industry, food industry and daily industry. Such as soy sauce, water lolly, peanut oil, vinegar, salad oil, ice lolly, cough relieves dew and wine.
| Item | Spec | Remark |
Pouch length | 50-300mm | Adjustable (coming within the length) |
Pouch width | 35 -100mm | Width fixed |
Filling capacity | 1-80ml | Based on dosing system |
Packing speed | 160- 600bags/min 4-12lanes | Based on material and bag size |
Feeding device | Sanitary pump | |
Standard cutting device | smooth cutting, with tear notch, dashed line cutting | Cold water circle (self-provided) |
Sealing type | 4 side sealing | |
Driver system | Servo motor driver | |
Applicable film | PET/AL/PE, PET/PE, NY/PE, NY/AL/PE etc. | |
Film width | 900mm | |
Film roller specification | Film outer diameter<300mm, film inner diameter 70-76mm | |
Voltage | 380V 3 phase 4 wires, 50Hz | Made in accordance with customer request |
Total power | 8.5Kw | |
G.W | 1500Kg | |
Package dimension | 1650 X 1400 X 20 00mm( L X W X H) | |
Optional device | Ink roller printer, Embossing type dating unit |
1.Nomally shipping steps:
2.Our packing and shipping:
![(4[KDGL_NF%E6%2]D`4JYP](http://sc02.alicdn.com/kf/HTB1yfSOaQT2gK0jSZFk763IQFXaB/224767400/HTB1yfSOaQT2gK0jSZFk763IQFXaB.png)
![0OC}YRDYXP])TO]QMXZ48IJ](http://sc01.alicdn.com/kf/HTB1txKNaUH1gK0jSZSy760tlpXaM/224767400/HTB1txKNaUH1gK0jSZSy760tlpXaM.png)
Pre-Sales Service:
* Inquiry and consulting support.
*Quickly reaction.
*Factory inspection available anytime.
After-Sales Service:
*Prompt technical support
*Engineers available to service machinery overseas
*Installation &commissioning,good training for customers.
![KE1PX$_SO]LLORZU3`DH8UW](http://sc02.alicdn.com/kf/HTB1FuKPaQH0gK0jSZPi761vapXaz/224767400/HTB1FuKPaQH0gK0jSZPi761vapXaz.png)
![RX2]L7{%NOW0`YXF9~)M{_G](http://sc02.alicdn.com/kf/HTB1UHmNaQP2gK0jSZPx761cQpXa8/224767400/HTB1UHmNaQP2gK0jSZPx761cQpXa8.png)
Q1.What's your delivery method?
A1:We commonly use sea transportation, using container to deliver the goods through Shanghai Port.
Q2.What products can you provide?
A2:Our main product includes powder mixers,granulating equipments,drying equipments,capsule fillers,blister packing machines,tablet/capsule counting filling line,ampoule/vial/oral liquid filling line includes ultrasonic washing machine,sterilization oven,filling capping machine,labeling machine.
Q3. What's the payment terms?
A3:We will confirm the payment with you when quoting, like FCA, CIF or others.T/T is the main payment.
Q4.How do you ensure your product quality?
A4:We conduct inspections in every production procedure, and for finished products, we will take 100% inspection depend on international standards according to customer's requirements.
Q5:Does the machine power voltage meet buyers' factory power source?
A5: We can do it as your request.
Q6: Is it difficult to install the machine ?
A6: For standard small machines, the machines will be packed with no take apart, it comes to you to be a complete machine; you just need to connect power and compressed air to machine, then begin to operate the machine.
For large size machines, we will take the machine apart, on condition that we do our best to keep the machine easy to assembly.
You will get videos and instructions about installation of machine from us.
