NCJ-C Semi-Automatic Capsule Filler
Introduction
NCJ-C Modification Type Capsule Filling Machine is new medical packing machinery with novel structure and artistic molding. It adopts mini computer speed-adjusting equipment, and to be controlled by the electric and pneumatic, equips electron automatic counting device. It can respectively finish the different processes separately such as arrangement, separating, filling, locking and etc. which reduce labor intensity, improve production efficiency, raise the accuracy of filling dosage. The machine meet with GMP standard.
This product is composed of sending capsule, arranging capsule and separation mechanism, medicines filling mechanism, tight locking mechanism, mini computer speed-adjusting mechanism, pneumatic and electric control system, protective equipment, vacuum pump, air pump accessories etc. It is suitable for both the domestic and imported capsules; certificated rate is more than 97%.
Main Technical specifications
| Maximum capacity | 12,500capsules/h |
| Capsule size | 00#,0#,1#,2#,3#,4# hard capsule |
| Power (kw) | 2.2 |
| Power supply | 380V 50Hz |
| Overall dimensions (mm) | 1350x700x1600(LxWxH) |
| Weight (kg) | 400 |
Configuration Part list for
NCJ-C semi-automatic Capsule filler
| 1 | Name | Model | Brand /manufacturer | Voltage | Qty | |
| 2 | Pneumatic elements | ModelAC-200 | Hualong group | 2 | ||
| 3 | Bearing | Many models | haerbin | Group | ||
| 4 | Reducer | WPWD-40 | Hangzhou yushen reducer factory | 2 | ||
| 5 | Motor | YS6324.7124 | Zhejiang linhai chunhua motor | 3 | ||
| 6 | Vacuum pump | XD-40 | Shanghai pujing | 1 | ||
| 7 | Stainless steel | 304 | China | Pieces | ||
| 8 | Inverter | N2 | T-VERTER from Taiwan | 2-220V | 2 | |
| 9 | Counter | SYJ-48A1 | Zhejiang ruian chaoke | AC-36V | 2 | |
| 10 | Heat relay | NR2-25 | CHNT | 1 | ||
| 11 | Button | LAS1-BY-11M | Zhejing hongbo | 8 | ||
| 12 | AC contactor | LC1-D09/10 | Schneider | AC-36V | 3 | |
| 13 | Transformer | BK-100 | Zhejiang transformer group, inlet 220,outlet 36V | 1 | ||
| 14 | Time relay | AH-3-3 | CKC-songling motor | AC-36V | 1 | |
| 15 | Miniature relay | HH564P | Zhejiang lierde | AC-36V | 2 | |
| 16 | Mini relay | DZ47-10/1P | CHNT | 1 | ||
| 17 | Mini breaker | DZ47-10/1P | CHNT | 1 | ||
| 18 | Proximity switch | GL-8F | OMRON | DCO-36V | 1 | |
| 19 | Emergency button | Y090-11M | Zhejiang niushi | 1 | ||
| 20 | Distance switch | AZ-7311 | Zhejiang niushi | 1 | ||
| 21 | Proximity switch | ANJK-5002C | Zhejiang taihua | 1 | ||
Real pictures for machines
1.Nomally shipping steps:
2.Our packing and shipping:
![(4[KDGL_NF%E6%2]D`4JYP](http://sc02.alicdn.com/kf/HTB1yfSOaQT2gK0jSZFk763IQFXaB/224767400/HTB1yfSOaQT2gK0jSZFk763IQFXaB.png)
![0OC}YRDYXP])TO]QMXZ48IJ](http://sc01.alicdn.com/kf/HTB1txKNaUH1gK0jSZSy760tlpXaM/224767400/HTB1txKNaUH1gK0jSZSy760tlpXaM.png)
Pre-Sales Service:
* Inquiry and consulting support.
*Quickly reaction.
*Factory inspection available anytime.
After-Sales Service:
*Prompt technical support
*Engineers available to service machinery overseas
*Installation &commissioning,good training for customers.
![KE1PX$_SO]LLORZU3`DH8UW](http://sc02.alicdn.com/kf/HTB1FuKPaQH0gK0jSZPi761vapXaz/224767400/HTB1FuKPaQH0gK0jSZPi761vapXaz.png)
![RX2]L7{%NOW0`YXF9~)M{_G](http://sc02.alicdn.com/kf/HTB1UHmNaQP2gK0jSZPx761cQpXa8/224767400/HTB1UHmNaQP2gK0jSZPx761cQpXa8.png)
Q1.What's your delivery method?
A1:We commonly use sea transportation, using container to deliver the goods through Shanghai Port.
Q2.What products can you provide?
A2:Our main product includes powder mixers,granulating equipments,drying equipments,capsule fillers,blister packing machines,tablet/capsule counting filling line,ampoule/vial/oral liquid filling line includes ultrasonic washing machine,sterilization oven,filling capping machine,labeling machine.
Q3. What’s the payment terms?
A3:We will confirm the payment with you when quoting, like FCA, CIF or others.T/T is the main payment, and D/P is acceptable as well.
Q4.How do you ensure your product quality?
A4:We conduct inspections in every production procedure, and for finished products, we will take 100% inspection depend on international standards according to customer's requirements.
Q5:Does the machine power voltage meet buyers' factory power source?
A5: We can do it as your request.
Q6: Is it difficult to install the machine ?
A6: For standard small machines, the machines will be packed with no take apart, it comes to you to be a complete machine; you just need to connect power and compressed air to machine, then begin to operate the machine.
For large size machines, we will take the machine apart, on condition that we do our best to keep the machine easy to assembly.
You will get videos and instructions about installation of machine from us.
