Disintegration Tester Instrument (BJ-3)


BJ-3 Disintegration tester

BJ series of instruments are used for detecting disintegration of solid in prescriptive conditions.

Applicable standards

National standard (Chinese codex)/2010/
Corporate standard( Disintegration tester)Q/12XQ0188-2010


1. There are eighteen tubes in three basket assemblies/
2. Each test station is driven independently. Auto stop at timing point
3. The bath liquid can achieve an even temperature.
4. A MPU is used to automatically control the temperature, time and frequency of nacelle up and down.
5. Parameters can be preset at anytime. The preset and real data can be displayed alternately in time.
6. Automation: Auto-test, auto-diagnose, auto-alarm.

Basket assemblies 3
Nacelle up and down frequency (30~32)/min
Nacelle up and down range (55±1)mm
Automatic time range (1~900)min
Temperature range Ambient to 45.0ºC
Accuracy of controlling temperature ±0.5ºC
Power 220V/50Hz/600W or 110V/60Hz/600W
Dimension (540 x 300 x 420)mm³

Disintegration Tester Instrument (BJ-3)

Disintegration Tester Instrument (BJ-3)                                  Disintegration Tester Instrument (BJ-3)

Packaging & Shipping

 1.Nomally shipping steps:


2.Our packing and shipping:


Our Services


     Pre-Sales Service:


         * Inquiry and consulting support.


         *Quickly reaction.


          *Factory inspection available anytime.



      After-Sales Service:


         *Prompt technical support


        *Engineers available to service machinery overseas


        *Installation &commissioning,good training for customers.



Our customer






Company Information




 Q1.What's your delivery method?

 A1:We commonly use sea transportation, using container to deliver the goods through Shanghai Port.


Q2.What products can you provide?

A2:Our main product includes powder mixers,granulating equipments,drying equipments,capsule fillers,blister packing machines,tablet/capsule counting filling line,ampoule/vial/oral liquid filling line includes ultrasonic washing machine,sterilization oven,filling capping machine,labeling machine.


Q3. What's the payment terms?

A3:We will confirm the payment with you when quoting, like FCA, CIF or others.T/T is the main payment.


Q4.How do you ensure your product quality?

A4:We conduct inspections in every production procedure, and for finished products, we will take 100% inspection depend on international standards according to customer's requirements.


Q5:Does the machine power voltage meet buyers' factory power source?

A5: We can do it as your request.


Q6: Is it difficult to install the machine ?

A6: For standard small machines, the machines will be packed with no take apart, it comes to you to be a complete machine; you just need to connect power and compressed air to machine, then begin to operate the machine.

For large size machines, we will take the machine apart, on condition that we do our best to keep the machine easy to assembly.

You will get videos and instructions about installation of machine from us.
