SD-015 Mini Spray Dryer is our latest type which adopts advanced international technology and spare parts. It assembles many of new design, for example, small shape for free moving, combining air compressor and electrical heater inside the cabinet, glass spray and cyclone separator for inspecting. All the data and function are controlled by PLC, English language.
Application range:
This type is popular in field of food, biology, material, pharmacy enterprise or university, R&D institute. Especially some non-heat material, that can be sprayed to power wonderfully, because material touch heat air in a little time, and high temperature do not destroy the component of production. Flavor, dairy, plant and vegetable extract liquid, pharmacy. Biology, chemical, material. Resins, ceramics and superconductors biochemical, etc.
Characteristic:
1. Designed for research and development.
2. Spray chamber, cyclone separator, receiving tank are all made of Borosilicate glass which can resist strong acid/alkali, high temperature. It can work in a no-pollution and stable environment, and the whole process can be inspected. All the spare parts are easy to install and wash.
3. The air compressor is no oil and do not pollute compress air. The power from receiving tank has a good flow. The sound is low than 60dB, and following the GMP standards.
4. Inlet/outlet temperature is accurate controlled by PID.
5. Supplied complete and ready for most spray drying applications.
6. The unit is self contained and supplied complete and ready for immediate operation.
7. Using preface touchable interface display operation, operator can control temperature, airflow volume, air pressure, pump speed and de-blocker frequency.
8. Product feeding with RS2559605 rotary pump, capacity is adjustable.
9. Out ring jacket supplying compressed air to nozzle and atomization is formed at the outlet of internal product pipe.
10. Automatic de-blocking device prevents the nozzle from becoming blocked and variably controlled.
11. Equipped with air filter to remove and collect fine particles in exhausted air.
Technical Specs:
| Max capacity | 1500-2000ml/h, |
| Temperature range of inlet air | 40-300ºC |
| Temperature range of outlet air | 40-140ºC |
| Precision of temperature | ± 1ºC |
| Dryer time | 1.0-1.5 S |
| Speed of squirt pump | 50-2000ml/h |
| Spray system | Two liquid nozzles (0.5/0.7/0.75/1.0/1.5/2.0/2.5) |
Spray direction: Downwards co-current
Heater power: 3kw 220V
1.Nomally shipping steps:
2.Our packing and shipping:
![(4[KDGL_NF%E6%2]D`4JYP](http://sc02.alicdn.com/kf/HTB1yfSOaQT2gK0jSZFk763IQFXaB/224767400/HTB1yfSOaQT2gK0jSZFk763IQFXaB.png)
![0OC}YRDYXP])TO]QMXZ48IJ](http://sc01.alicdn.com/kf/HTB1txKNaUH1gK0jSZSy760tlpXaM/224767400/HTB1txKNaUH1gK0jSZSy760tlpXaM.png)
Pre-Sales Service:
* Inquiry and consulting support.
*Quickly reaction.
*Factory inspection available anytime.
After-Sales Service:
*Prompt technical support
*Engineers available to service machinery overseas
*Installation &commissioning,good training for customers.
![KE1PX$_SO]LLORZU3`DH8UW](http://sc02.alicdn.com/kf/HTB1FuKPaQH0gK0jSZPi761vapXaz/224767400/HTB1FuKPaQH0gK0jSZPi761vapXaz.png)
![RX2]L7{%NOW0`YXF9~)M{_G](http://sc02.alicdn.com/kf/HTB1UHmNaQP2gK0jSZPx761cQpXa8/224767400/HTB1UHmNaQP2gK0jSZPx761cQpXa8.png)
Q1.What's your delivery method?
A1:We commonly use sea transportation, using container to deliver the goods through Shanghai Port.
Q2.What products can you provide?
A2:Our main product includes powder mixers,granulating equipments,drying equipments,capsule fillers,blister packing machines,tablet/capsule counting filling line,ampoule/vial/oral liquid filling line includes ultrasonic washing machine,sterilization oven,filling capping machine,labeling machine.
Q3. What's the payment terms?
A3:We will confirm the payment with you when quoting, like FCA, CIF or others.T/T is the main payment.
Q4.How do you ensure your product quality?
A4:We conduct inspections in every production procedure, and for finished products, we will take 100% inspection depend on international standards according to customer's requirements.
Q5:Does the machine power voltage meet buyers' factory power source?
A5: We can do it as your request.
Q6: Is it difficult to install the machine ?
A6: For standard small machines, the machines will be packed with no take apart, it comes to you to be a complete machine; you just need to connect power and compressed air to machine, then begin to operate the machine.
For large size machines, we will take the machine apart, on condition that we do our best to keep the machine easy to assembly.
You will get videos and instructions about installation of machine from us.
