Main application:
This line is composed of QCL120(100, 80) vertical washing machine, KSZ620/60(620/43) sterilizing tunnel, AGF12(10A, 10, 8) filling & sealing machine. It is divided into three zones of washing, drying & sterilizing, filling & sealing. Each machine can function independently, or be connected as a compact line. It could finish processing procedures such as: Water sprinkling, ultrasonic washing, ampoules infeed by screw conveyer, Turn ampoules by manipulator, water flushing(interior and exterior), air flushing(interior and exterior), preheating, drying & sterilizing, cooling, (front gas charging), filling, (rear gas charging), preheating, sealing, and etc. It is mainly used for production of ampoule in pharmaceutical factories. The improved type is suitable for not only ampoules but also vials production.
Characteristic:
It adopts ultrasonic washing and washing by alternant jetting water and airflow. It is the most popular and with highest clarity washing equipment in the world. In whole washing process, three washing mediums adopt independent needles, each group of needle only flush one washing medium, avoids cross contamination, which meets GMP requirement much more.
It adopts the principle of laminar flow and hot air sterilizing technics, which can make containers reach 3 Grade National cleanliness(100 Class U. S. A. Industrial standard). It is the most popular sterilizing & drying equipment and has best sterilizing effect. It has equal heat distribution and good eliminate pyrogen effect.
It adopts starwheel to input bottles instead of sector block, adopts three segments type walking beam instead of integer type, adopts synchronous gear belt transmission structure instead of cam. It is the most popular filling and sealing device in the world. And it also improves running balance and qualified rate of equipment.
It adopts advanced PLC control man-machine interface operation which can not only control the whole line but also control single machine. It guarantees normal running of the whole compact line, with high automation degree, few operator and low labor intensity.
Model | Suitable ampoule | Output capacity | Power | Net weight | Overall dimensions |
BXSZ1/ 20-G | 1-20ml | 10000-46000 pcs/h | 96.15kw, normal working consumption:51kw | 10200kg | 11800×2850×2380mm |
BXSZ1/ 20-F2 | 1-20ml | 10000-33000 pcs/h | 96.15kw,normal working consumption:51kw | 10200kg | 11180×2850×2380mm |
BXSZ1/ 10-F1 | 1-10ml | 10000-34000 pcs/h | 86.15kw,normal working consumption:51kw | 9200kg | 10600×2620×2380mm |
BXSZ1/ 20-E2 | 1-20ml | 6000-28000 pcs/h | 86.15kw,normal working consumption:51kw | 9200kg | 10600×2620×2380mm |
BXSZ1/ 20-E1 | 1-5ml | 10000-28000 pcs/h | 63.65kw,normal working consumption:41kw | 8600kg | 8900×2620×2380mm |
BXSZ1/ 20-D | 1-20ml | 6000-23000 pcs/h | 63.65kw,normal working consumption:41kw | 8200kg | 8900×2620×2380mm |
BXSZ1/ 20-C | 1-20ml | 4000-12000 pcs/h | 63.65kw,normal working consumption:41kw | 7200kg | 8300×2420×2380mm |
1.Nomally shipping steps:
2.Our packing and shipping:
Pre-Sales Service:
* Inquiry and consulting support.
*Quickly reaction.
*Factory inspection available anytime.
After-Sales Service:
*Prompt technical support
*Engineers available to service machinery overseas
*Installation &commissioning,good training for customers.
Q1.What's your delivery method?
A1:We commonly use sea transportation, using container to deliver the goods through Shanghai Port.
Q2.What products can you provide?
A2:Our main product includes powder mixers,granulating equipments,drying equipments,capsule fillers,blister packing machines,tablet/capsule counting filling line,ampoule/vial/oral liquid filling line includes ultrasonic washing machine,sterilization oven,filling capping machine,labeling machine.
Q3. What's the payment terms?
A3:We will confirm the payment with you when quoting, like FCA, CIF or others.T/T is the main payment.
Q4.How do you ensure your product quality?
A4:We conduct inspections in every production procedure, and for finished products, we will take 100% inspection depend on international standards according to customer's requirements.
Q5:Does the machine power voltage meet buyers' factory power source?
A5: We can do it as your request.
Q6: Is it difficult to install the machine ?
A6: For standard small machines, the machines will be packed with no take apart, it comes to you to be a complete machine; you just need to connect power and compressed air to machine, then begin to operate the machine.
For large size machines, we will take the machine apart, on condition that we do our best to keep the machine easy to assembly.
You will get videos and instructions about installation of machine from us.
