Updated 2 Heads Ampoule Filling Sealing Machine (AAG-2)


Detailed Product Description

Ampoule drawing, filling and sealing combined equipment
With WATSON UK peristaltic pump
Panasonic touch screen control...

The machine is a new generation of the ampoule drawing, filling and sealing combined equipment for injections. It adopts the rectangular feeding instead of the traditional ampoule feeding methods. In such case, the feeding is steady with no easy broken ampoule. A modern clutch is mouthed under the ampoule feed hopper. Therefore, the ampoule feeding can be stopped at any time while the machines is still running. So the ampoule lost can be reduced. In the part of stopping filling where changes electromagnetic switch into mechanical switch. It is reliable and durable. Bottle reverse and bottle arranging stricture are used in the device of bottle outlet. It reduces the broken rate of the finished products of ampoules tremendously.

Main technical specifications:

Dimension: 1100×720×1400mm
Filling heads: 2 heads
Model:    1-2ml,5-10ml,20ml
Capacity:    40-65 ampoules/min
Fuel consumption: gas 1m3/h,LPG 0.6kg/h
Consumption of Oxygen: 4kg/h
Motor power:  0.37kW
Power supply: 220V 50Hz
Weight:         250 kg

Updated 2 Heads Ampoule Filling Sealing Machine (AAG-2)
Updated 2 Heads Ampoule Filling Sealing Machine (AAG-2)

No. Name Model Qty Manufacturer
1 Motor JW7114-0.37kW 1set Shanghai Regal-Beloit China and USA joint-venture
2 Inverter BFV00042GK 0.4kW 1set Taiwan DELTA
3 peristaltic pump 313D 2 sets UK,

4 Step motor 2S56Q 2 sets KINCO
5 Driver 2M530 2sets KINCO
6 PLC VB1-14MT-D 1set Taiwan
7 Touch screen MT6070IH2 1set Taiwan
8 linear guide rail
1group Japan
9 Main shaft 40Gr Ø40 1piece UNIMACH CHINA Quenching and tempering:
10 Cam and gear 45 One group UNIMACH CHINA Quenching and tempering
and surface hardening:HRC48-52
11 Stainless steel 304
