Un-240 Automatic Powder Packing Machine

Quantity:
Automatic Powder Packing Machine

Un-240 Automatic Powder Packing Machine
Application:
  This series installed powder auger dosing system.can pack powder products such as milk powder, medicine and chemicals powder, etc.

  Features   :
1.Bag-making, measuring, filling, sealing, cutting and counting are all finished automatically.
2. Either under set length control or photo-electronic color tracing, we set bag length and cut in one step. Time and film saving.
  3. The temperature is under independent PID control, more suitable for different packing materials.
  4   . The driving system is simple and reliable, and maintenance is easy.
  5   . Applicable material should be composite films like: PET/PE, Paper/PE, PET/AL/PE, OPP/PE.
Technical Specification:
Item Description of Item
1 Machine Automatic Powder Packing Machine
Model UN-240 (max film width to be 220mm through)
Sealing type 3-side sealing
Measurement Auger type (2-10gr,adjustable)
Hopper volume 13L
Cutting type Zigzag cutter
Sealer Horizontal sealer:line
Vertical sealer: diamond
Speed 40 - 60bag/min (Depend on Products)
Bag size W:60mm× L:85mm
Film width 120mm
Total power 2150W
Voltage 220V 50Hz 1P or 380V 50Hz 3P
Machine Net Weight 200Kg
Mainframe Dimensions L×W×H: (625x751x1558)mm
Material Stainless steel 304
Includes Inverter, photo sensor, short output belt conveyor,ribbon printer, a vibrator, one bag former(120mm) and one auger set (2-10gr)
Optional Date coding ribbon printer as below
Straight cutter
Bag samples:
Un-240 Automatic Powder Packing Machine


Packaging & Shipping

 1.Nomally shipping steps:

 S45PNZ%`OL`M6O8H}V(SDJ

2.Our packing and shipping:

(4[KDGL_NF%E6%2]D`4JYP

Our Services

 0OC}YRDYXP])TO]QMXZ48IJ

     Pre-Sales Service:



         * Inquiry and consulting support.



         *Quickly reaction.



          *Factory inspection available anytime.





      After-Sales Service:



         *Prompt technical support



        *Engineers available to service machinery overseas



        *Installation &commissioning,good training for customers.





Our customer

 KE1PX$_SO]LLORZU3`DH8UW



Certifications

[$X~Z{0)[{$PW5F}H666N6M



Company Information

RX2]L7{%NOW0`YXF9~)M{_G


FAQ

 Q1.What's your delivery method?

 A1:We commonly use sea transportation, using container to deliver the goods through Shanghai Port.



Q2.What products can you provide?

A2:Our main product includes powder mixers,granulating equipments,drying equipments,capsule fillers,blister packing machines,tablet/capsule counting filling line,ampoule/vial/oral liquid filling line includes ultrasonic washing machine,sterilization oven,filling capping machine,labeling machine.



Q3. What's the payment terms?

A3:We will confirm the payment with you when quoting, like FCA, CIF or others.T/T is the main payment.



Q4.How do you ensure your product quality?

A4:We conduct inspections in every production procedure, and for finished products, we will take 100% inspection depend on international standards according to customer's requirements.



Q5:Does the machine power voltage meet buyers' factory power source?

A5: We can do it as your request.



Q6: Is it difficult to install the machine ?

A6: For standard small machines, the machines will be packed with no take apart, it comes to you to be a complete machine; you just need to connect power and compressed air to machine, then begin to operate the machine.

For large size machines, we will take the machine apart, on condition that we do our best to keep the machine easy to assembly.

You will get videos and instructions about installation of machine from us.
