1. It can count accurately and fill round tablets, pills, capsules, transparent soft gelatin capsules, irregular pills into container bottles.
2. High speed: It has 32 channels that can reach 60-120 bottles per min.
3. The machine would auto-alarm workers when the bottles supplying is not enough or the bottles blocked. The machine would pause there. When the problems are solved, the machine can return back to normal. It doesn't need certain people to monitor it.
4.3-stages dust collection design, the dust is removed when granules dropping, which avoid dust contamination.
5. Key pneumatic parts, especially integrated solenoid valve and cylinder for shutting door, are from Japan CKD. Ensures filling accuracy.
6. Use IR (infrared ray) dynamic scan technology, counting accuracy with alarm function when problems occur.
7. You can set the quantity of the drugs (15~9999) through the touch screen. Monitor the dropping status on each channel.
Model | SL32B |
Max speed (drugs/min) | 12000 |
No. of channels | 32 |
Filling quantity per bottle | 15-9999 |
Bottle diameter, height | Φ 30~Φ 75mm, 40-250mm |
Hopper volume | 2X40L |
Thickness, diameter and length | T3.5~10mm, Φ 3.5~15mm, L3.5~20mm |
Compressed air supply | 0.5MPa |
Power supply | 220V50HZ |
Total power | 1KW |
Conveyor length | 3000mm |
Dimension | 1900mmx3000mmx1670mm |
Net weight | 1000kg |
1.Nomally shipping steps:
2.Our packing and shipping:
Pre-Sales Service:
* Inquiry and consulting support.
*Quickly reaction.
*Factory inspection available anytime.
After-Sales Service:
*Prompt technical support
*Engineers available to service machinery overseas
*Installation &commissioning,good training for customers.
Q1.What's your delivery method?
A1:We commonly use sea transportation, using container to deliver the goods through Shanghai Port.
Q2.What products can you provide?
A2:Our main product includes powder mixers,granulating equipments,drying equipments,capsule fillers,blister packing machines,tablet/capsule counting filling line,ampoule/vial/oral liquid filling line includes ultrasonic washing machine,sterilization oven,filling capping machine,labeling machine.
Q3. What’s the payment terms?
A3:We will confirm the payment with you when quoting, like FCA, CIF or others.T/T is the main payment.
Q4.How do you ensure your product quality?
A4:We conduct inspections in every production procedure, and for finished products, we will take 100% inspection depend on international standards according to customer's requirements.
Q5:Does the machine power voltage meet buyers' factory power source?
A5: We can do it as your request.
Q6: Is it difficult to install the machine ?
A6: For standard small machines, the machines will be packed with no take apart, it comes to you to be a complete machine; you just need to connect power and compressed air to machine, then begin to operate the machine.
For large size machines, we will take the machine apart, on condition that we do our best to keep the machine easy to assembly.
You will get videos and instructions about installation of machine from us.
