High-speed powder filling and capping machine
II technical parameter and main component
Bottle feeding machine(double rails bottle turntable)
This machine is composed of turn table, bottle transfer channel, the machine order the bottle in one line, and delivery it to the washing machine. This machine can store the bottle, buffering the bottle, and change the bottle flow direction.
Application: round bottle that can stand on the table steady
Turn table diameter. : φ900mm
transfer capability : comply with the filling machine
power supply: 220V 60HZ
power: 0.12KW
outside dimension: 950×1400×950mm
Main component
the table, and surrounding plate is imported good quality SUS 304/2B
regulating motor:Shanghai
button: Schneider
Linear air washing machine
The blowing needle is pressed down to the inside of the bottle for cleaning with the host synchronously. When the blowing and suction needle tube extends into the bottle mouth for a certain length, the sealing gasket on the needle tube seat contacts the surface of the bottle mouth and is properly compressed. At the same time, the mechanical valve is opened, the air inlet pipe is connected and air is blown into the bottle through the needle tube, and the air blown into the bottle is sucked out by the suction needle tube.
What is blown in from the needle tube is the filtered dry compressed air, which forms a gas circulation in the bottle, powerfully flushes the inner surface of the container, so that the dust in the bottle is suspended; the whirlpool air pump that runs all the time removes it from a slightly larger diameter The suction pipe is discharged to complete the cleaning and dust removal process.
Yield capacity: 50-60 bottles/min
power: 1.8KW
compressed air: 380V 50Hz
compressed air consumption: 10m3/h,0.3~0.4kg/cm2
outside dimension: 2500×900×1850mm
Powder Filling Capping Machine
Purpose and performance
This equipment is a kind of machine type with functions of filling.caps screwing and capping. Single-headed or double. Headed filling/capping is available according to clients’specific requirements. It is applicable to packaging of powder solid particles in pharmaceutical and food industry . this machine has compact structure and is simple in operation.
Specification
Scope:30-60ML
Filling station: : 2
Output:50-60BPM
Packing Error:1±%
Add cap pass rate:99%
Weight:500㎏
Power:380V 50HZ 2KW
outside dimension: 3000×1450×1850mm
Machine Line drawing
1.Nomally shipping steps:
2.Our packing and shipping:
Pre-Sales Service:
* Inquiry and consulting support.
*Quickly reaction.
*Factory inspection available anytime.
After-Sales Service:
*Prompt technical support
*Engineers available to service machinery overseas
*Installation &commissioning,good training for customers.
Q1.What's your delivery method?
A1:We commonly use sea transportation, using container to deliver the goods through Shanghai Port.
Q2.What products can you provide?
A2:Our main product includes powder mixers,granulating equipments,drying equipments,capsule fillers,blister packing machines,tablet/capsule counting filling line,ampoule/vial/oral liquid filling line includes ultrasonic washing machine,sterilization oven,filling capping machine,labeling machine.
Q3. What's the payment terms?
A3:We will confirm the payment with you when quoting, like FCA, CIF or others.T/T is the main payment.
Q4.How do you ensure your product quality?
A4:We conduct inspections in every production procedure, and for finished products, we will take 100% inspection depend on international standards according to customer's requirements.
Q5:Does the machine power voltage meet buyers' factory power source?
A5: We can do it as your request.
Q6: Is it difficult to install the machine ?
A6: For standard small machines, the machines will be packed with no take apart, it comes to you to be a complete machine; you just need to connect power and compressed air to machine, then begin to operate the machine.
For large size machines, we will take the machine apart, on condition that we do our best to keep the machine easy to assembly.
You will get videos and instructions about installation of machine from us.
