Fluid Bed Dryer Granulator Machine with Pharmaceutical
Scope of applications
Pharmaceutical industry: Tablet capsule, low sugar or no sugar granule of Chinese traditional medicine.
Foodstuff: Cocoa, coffee, milk powder, juice of granulate, flavoring and so on.
Other industries: Pesticide, feed, chemical fertilizer, pigment, dyestuff and so on.
Drying: Powder or granule state of wet material
Coating: Protection layer, color, controlled release, film, or bowels solved coating of granules and pills.
Principles
The powder granule the container (fluidization bed) appear the state of fluidization, It is pre-heated and mixed with clean and heated air. At the same time the solution of adhesive solvent is fogged and sprayed into the container. It makes the some particles become granulating that contains adhesive. Being of unceasing dry through hot air, the moisture in the granulating is evaporated and the adhesive is solidification. The process is carried out continuously. Finally it forms ideal, uniform and porous granules.
Spray gun(three nozzles)
| Item | Unit | Type | ||||||||||
| 3 | 5 | 15 | 30 | 60 | 120 | 200 | 300 | 500 | ||||
| Container | Volume | L | 12 | 22 | 45 | 100 | 220 | 420 | 670 | 1000 | 1500 | |
| Diameter | MM | 300 | 400 | 550 | 700 | 1000 | 1200 | 1400 | 1600 | 1800 | ||
| Output capacity | Min | KG/batch | 1.5 | 4 | 10 | 15 | 30 | 80 | 100 | 150 | 250 | |
| Max | KG/batch | 4.5 | 6 | 20 | 45 | 90 | 160 | 300 | 450 | 750 | ||
| Fan | Capacity | m3/H | 1000 | 1200 | 1400 | 1800 | 3000 | 4500 | 6000 | 7000 | 8000 | |
| Pressure | MM H2O | 375 | 375 | 480 | 480 | 950 | 950 | 950 | 950 | 950 | ||
| Power | KW | 3 | 4 | 5.5 | 7.5 | 11 | 18.5 | 22 | 30 | 45 | ||
| Steam expenditure | KG/H | 15 | 23 | 42 | 70 | 141 | 211 | 282 | 366 | 451 | ||
| Compressed air expenditure | m3/min | 0.9 | 0.9 | 0.9 | 0.9 | 1.0 | 1.0 | 1.1 | 1.5 | 1.5 | ||
| Weight of the main body | KG | 500 | 700 | 900 | 1000 | 1100 | 1500 | 1500 | 1800 | 2000 | ||
| Steam pressure | MPA | 0.3-0.6 | ||||||||||
| Temperature | ºC | Adjustable at the range from room temperature to 120ºC | ||||||||||
| Working time | MIN | Decided in accordance with the properties of raw materials | ||||||||||
| Field | % | ≥99 | ||||||||||
| Noise | DB(A) | ≤75Db(When installation, main machine is separated from fan) | ||||||||||
| Size (L×W×H) | M | 1.0×0.6 ×2.1 |
1.2×0.7 ×2.3 |
1.25×0.9 ×2.5 |
1.6×1.1 ×2.5 |
1.85×1.4 ×3 |
2.2×1.65 ×3.3 |
2.34×1.7 ×3.8 |
2.8×2.0 ×4.0 |
3×2.25 ×4.4 |
||
1.Nomally shipping steps:
2.Our packing and shipping:
Pre-Sales Service:
* Inquiry and consulting support.
*Quickly reaction.
*Factory inspection available anytime.
After-Sales Service:
*Prompt technical support
*Engineers available to service machinery overseas
*Installation &commissioning,good training for customers.
Q1.What's your delivery method?
A1:We commonly use sea transportation, using container to deliver the goods through Shanghai Port.
Q2.What products can you provide?
A2:Our main product includes powder mixers,granulating equipments,drying equipments,capsule fillers,blister packing machines,tablet/capsule counting filling line,ampoule/vial/oral liquid filling line includes ultrasonic washing machine,sterilization oven,filling capping machine,labeling machine.
Q3. What's the payment terms?
A3:We will confirm the payment with you when quoting, like FCA, CIF or others.T/T is the main payment.
Q4.How do you ensure your product quality?
A4:We conduct inspections in every production procedure, and for finished products, we will take 100% inspection depend on international standards according to customer's requirements.
Q5:Does the machine power voltage meet buyers' factory power source?
A5: We can do it as your request.
Q6: Is it difficult to install the machine ?
A6: For standard small machines, the machines will be packed with no take apart, it comes to you to be a complete machine; you just need to connect power and compressed air to machine, then begin to operate the machine.
For large size machines, we will take the machine apart, on condition that we do our best to keep the machine easy to assembly.
You will get videos and instructions about installation of machine from us.
