It is the latest scientific products for pharmaceutical factory and health care factory as well as foodstuff process factory. It is adopted with micro-computer PLC man-machine interface to operation, frequency converter, high automation, ease of operation, advanced technology, full purpose, long durability, in accordance with GMP requirement, currently it is the ideal packaging equipment with high popularity. The products have been passed the provincial science and technology appraisal.
Features:
With inductive self-checking mechanism established, it can eliminate by itself the waste plate with lack of particle; The qualified rate reaches 100%
The main transmission is adopted with swinging pin-wheel reducer. With long life, low noise, stable running.
Plate structure, adjustable stroke, so it can be suited for such as circle, ellipses, square, triangle, or irregular shape, and suitable for multiple specifications of products, equipped with cursor trace registration, good looking sealing.
| Punching time (t/min) | AL-AL 6-25, Al-Plastic 6-50, and Paper-Plastic 6-50 |
| Max capacity (pcs/h) | AL-AL ≤ 45000, AL-Plastic≤ 110000 |
| Max forming area and depth (mm) | AL-AL 130x130x14, AL-Plastic 130x130x26 |
| Stroke (mm) | 40-140(designed according to requirement) |
| Standard plate/pack (mm) | 80x57 (designed according to requirement) |
| Air pressure (Mpa) | 0.4-0.6, (air supply) ≥ 0.2m3/min |
| Total power | 380V/220V 50Hz, 3.6kw |
| Main motor power (Kw) | 0.75 |
| Forming aluminum (mm) | 0.085-0.1x140 |
| PVC hard pieces (mm) | 0.15-0.5x140 |
| PTP Aluminum Foil (mm) | 0.02-0.035x140 |
| Dialysis paper(mm) | 50-100g x140 |
| tooling cooling | Running water or recycling water |
| Overall dimension (mm) | 2300*560*1410 (L x W x H) |
| Weight (kg) | 700 |
1.Nomally shipping steps:
2.Our packing and shipping:
![(4[KDGL_NF%E6%2]D`4JYP](http://sc02.alicdn.com/kf/HTB1yfSOaQT2gK0jSZFk763IQFXaB/224767400/HTB1yfSOaQT2gK0jSZFk763IQFXaB.png)
![0OC}YRDYXP])TO]QMXZ48IJ](http://sc01.alicdn.com/kf/HTB1txKNaUH1gK0jSZSy760tlpXaM/224767400/HTB1txKNaUH1gK0jSZSy760tlpXaM.png)
Pre-Sales Service:
* Inquiry and consulting support.
*Quickly reaction.
*Factory inspection available anytime.
After-Sales Service:
*Prompt technical support
*Engineers available to service machinery overseas
*Installation &commissioning,good training for customers.
![KE1PX$_SO]LLORZU3`DH8UW](http://sc02.alicdn.com/kf/HTB1FuKPaQH0gK0jSZPi761vapXaz/224767400/HTB1FuKPaQH0gK0jSZPi761vapXaz.png)
![RX2]L7{%NOW0`YXF9~)M{_G](http://sc02.alicdn.com/kf/HTB1UHmNaQP2gK0jSZPx761cQpXa8/224767400/HTB1UHmNaQP2gK0jSZPx761cQpXa8.png)
Q1.What's your delivery method?
A1:We commonly use sea transportation, using container to deliver the goods through Shanghai Port.
Q2.What products can you provide?
A2:Our main product includes powder mixers,granulating equipments,drying equipments,capsule fillers,blister packing machines,tablet/capsule counting filling line,ampoule/vial/oral liquid filling line includes ultrasonic washing machine,sterilization oven,filling capping machine,labeling machine.
Q3. What's the payment terms?
A3:We will confirm the payment with you when quoting, like FCA, CIF or others.T/T is the main payment.
Q4.How do you ensure your product quality?
A4:We conduct inspections in every production procedure, and for finished products, we will take 100% inspection depend on international standards according to customer's requirements.
Q5:Does the machine power voltage meet buyers' factory power source?
A5: We can do it as your request.
Q6: Is it difficult to install the machine ?
A6: For standard small machines, the machines will be packed with no take apart, it comes to you to be a complete machine; you just need to connect power and compressed air to machine, then begin to operate the machine.
For large size machines, we will take the machine apart, on condition that we do our best to keep the machine easy to assembly.
You will get videos and instructions about installation of machine from us.
