This machine is suitable for the blister card packing of battery, stationery, food, medical equipment, toys, hard ward, electronics, auto parts, daily use product, cosmetic etc, such as the injector, solid gum, toy car, scissor, flashlight, battery, spark Plug, lip stick, hook, shaver, pencil etc.
Working process:
PVC unreeling PVC heating blister tray forming servo drawing blister tray cutting PVC waste edge reeling blister tray delivery and transferring product feeding automatic card feeding heat sealing final product output.
2. Some technical features
1) Mechanical transmission, servo motor driving, encoder control, reasonable Structure, easy operation.
2) Rotating table type heat sealing which will improve the sealing result, reduce the mould expense and help to change the mould conveniently.
3) 304 stainless steel frame, beautiful appearance, convenient for cleaning.
4) PLC control system, frequency speed adjust, which will help to reduce the noise And improve the running stability of the machine.
5) Photoelectrical control, auto detection.
6) The whole machine is separately designed, it is convenient to delivery with lift.
7) To design the mould and auto feeding method according to the product shape.
3. Main technical Parameters
Maximum size of card | Width: 3 5 0mm , thickness: 250-700g |
Maximum size of PVC | Width: 2 50mm , thickness: 0.25-0.40mm |
Cutting frequency | 15- 2 5 times/ minute |
Travel range | 225 mm |
Max. Forming depth | Standard: ≤ 38mm, special: ≤ 60mm |
Max. Forming area | 340*210*38mm |
Noise | 60-70dB |
Air pressure | 0.5-0. 7 Mpa |
Air flow | ≥0. 3 m ³ /min |
Total power | 380V 50Hz 9 kW , 3-phase, 4-wire |
Main motor power | 1.5kW |
Overall dimension | 530 0 *8 40 * 1 67 0mm ( L * W * H ) |
Machine weight | 2 500kg |
1.Nomally shipping steps:
2.Our packing and shipping:
![(4[KDGL_NF%E6%2]D`4JYP](http://sc02.alicdn.com/kf/HTB1yfSOaQT2gK0jSZFk763IQFXaB/224767400/HTB1yfSOaQT2gK0jSZFk763IQFXaB.png)
![0OC}YRDYXP])TO]QMXZ48IJ](http://sc01.alicdn.com/kf/HTB1txKNaUH1gK0jSZSy760tlpXaM/224767400/HTB1txKNaUH1gK0jSZSy760tlpXaM.png)
Pre-Sales Service:
* Inquiry and consulting support.
*Quickly reaction.
*Factory inspection available anytime.
After-Sales Service:
*Prompt technical support
*Engineers available to service machinery overseas
*Installation &commissioning,good training for customers.
![KE1PX$_SO]LLORZU3`DH8UW](http://sc02.alicdn.com/kf/HTB1FuKPaQH0gK0jSZPi761vapXaz/224767400/HTB1FuKPaQH0gK0jSZPi761vapXaz.png)
![RX2]L7{%NOW0`YXF9~)M{_G](http://sc02.alicdn.com/kf/HTB1UHmNaQP2gK0jSZPx761cQpXa8/224767400/HTB1UHmNaQP2gK0jSZPx761cQpXa8.png)
Q1.What's your delivery method?
A1:We commonly use sea transportation, using container to deliver the goods through Shanghai Port.
Q2.What products can you provide?
A2:Our main product includes powder mixers,granulating equipments,drying equipments,capsule fillers,blister packing machines,tablet/capsule counting filling line,ampoule/vial/oral liquid filling line includes ultrasonic washing machine,sterilization oven,filling capping machine,labeling machine.
Q3. What's the payment terms?
A3:We will confirm the payment with you when quoting, like FCA, CIF or others.T/T is the main payment.
Q4.How do you ensure your product quality?
A4:We conduct inspections in every production procedure, and for finished products, we will take 100% inspection depend on international standards according to customer's requirements.
Q5:Does the machine power voltage meet buyers' factory power source?
A5: We can do it as your request.
Q6: Is it difficult to install the machine ?
A6: For standard small machines, the machines will be packed with no take apart, it comes to you to be a complete machine; you just need to connect power and compressed air to machine, then begin to operate the machine.
For large size machines, we will take the machine apart, on condition that we do our best to keep the machine easy to assembly.
You will get videos and instructions about installation of machine from us.
