High Efficiency Fluid Bed Dryer (GFG)
High Efficiency Fluid Bed Dryer (GFG)
Features
The structure of fluidization bed is of round so as to avoid dead corner.
Inside the hopper there is a stirring device in order to avoid agglomeration of raw material and forming canal of flow.
The granule is discharged through the method of turning over. It is very convenient and full. The discharged system can be designed as request too.
It is operated at he conditions of negative pressure and seal. The air is filtered. Therefore it is simple in operation and convenient for cleaning. It is an ideal equipment that is in conformity with the requirements of GMP.
The drying speed is fast and the temperature is uniform. The drying time is 20-30 minutes normally.
Principle
Purified and heated air is introduced from the bottom through suction fan and passed through the screen plate of raw material. In the work chamber, the state of fluidization is formed through stirring and negative pressure. The moisture is evaporated and removed rapidly and the raw material is dried quickly.
Applications
Screw extruded granules, sway produced YK series Granules and granules produced by GHL series Granulator.
Suitable for drying humidity block or powder raw material in Pharmaceutical, foodstuff, feed, chemical industries and so on fields.
Large granules, small blocks and adhesive material.
The materials that volumes may vary during drying process.
| item | spec | |||||||||||
| Input capacity | Kg/batch | 60 | 100 | 120 | 150 | 200 | 300 | 500 | 1000 | |||
| fan | velocity | m3/h | 2361 | 3488 | 4000 | 4901 | 6032 | 7800 | 10800 | 15000 | ||
| air pressure | mmH2O | 594 | 533 | 533 | 679 | 787 | 950 | 950 | 1200 | |||
| power | kw | 7.5 | 11 | 15 | 18.5 | 22 | 30 | 45 | 75 | |||
| stirring power | kw | 0.55 | 0.55 | 0.55 | 0.55 | 0.75 | 1.5 | 1.5 | 2.2 | |||
| stirring speed | rpm | 11 | ||||||||||
| consume of steam | kg/h | 141 | 170 | 170 | 240 | 282 | 366 | 451 | 800 | |||
| time of operation | min | 15-30 (depends on material) | ||||||||||
| height of main machine | mm | 2700 | 2900 | 2900 | 2900 | 3300 | 3800 | 4200 | 5800 | |||
1.Nomally shipping steps:
2.Our packing and shipping:
Pre-Sales Service:
* Inquiry and consulting support.
*Quickly reaction.
*Factory inspection available anytime.
After-Sales Service:
*Prompt technical support
*Engineers available to service machinery overseas
*Installation &commissioning,good training for customers.
Q1.What's your delivery method?
A1:We commonly use sea transportation, using container to deliver the goods through Shanghai Port.
Q2.What products can you provide?
A2:Our main product includes powder mixers,granulating equipments,drying equipments,capsule fillers,blister packing machines,tablet/capsule counting filling line,ampoule/vial/oral liquid filling line includes ultrasonic washing machine,sterilization oven,filling capping machine,labeling machine.
Q3. What's the payment terms?
A3:We will confirm the payment with you when quoting, like FCA, CIF or others.T/T is the main payment.
Q4.How do you ensure your product quality?
A4:We conduct inspections in every production procedure, and for finished products, we will take 100% inspection depend on international standards according to customer's requirements.
Q5:Does the machine power voltage meet buyers' factory power source?
A5: We can do it as your request.
Q6: Is it difficult to install the machine ?
A6: For standard small machines, the machines will be packed with no take apart, it comes to you to be a complete machine; you just need to connect power and compressed air to machine, then begin to operate the machine.
For large size machines, we will take the machine apart, on condition that we do our best to keep the machine easy to assembly.
You will get videos and instructions about installation of machine from us.
