LFP-150A Vertical Capsule Sorter Polisher
LFP-150A Vertical Capsule Sorter Polisher
Introduction
LFP-150A series capsule sorter polisher machine has dual functions of capsule polishing and lifting. The entrance of the machine can be connected with any type of capsule filling machine. The export can be connected with capsule sorting device and metal testing machine. To achieve polishing, lifting, sorting, testing of the production model. The machine adopts a number of new technologies and human design concepts, with the following outstanding features:
1: It has the dual function of polishing and lifting the capsule, leaving a high space for connecting subsequent equipment;
2: The entrance and exit of the machine can be adjusted by 360 degrees, which is convenient for production and saves space.
3: Capsule sorting device can automatically sort the capsule with light loading, empty shell, fragments and body cap capsule
4: The whole machine adopts the quick-mounting type connection structure, which makes the disassembly and installation of the machine more convenient and fast.
5: All parts contacting with drugs shall be made of 316L materials or materials meeting the requirements of modern drug production requments.
6: The brushes on the main shaft can be detached and cleaned thoroughly. The whole machine can be cleaned without dead angle. It meets the requirements of GMP.
Technical specifications
| Model | LFP-150A |
| Suitable capsule model | 00 # 0 # 1 # 2 # 3 # 4 # |
| Maximum production efficiency(Granule/Hours) | 450,000 |
| Entrance height(Mm) | 730 |
| Exit height(Mm) | 1100 |
| Power Supply Index | 1PH 220V/110V 50 Hz/60 Hz 0.20 kw |
| Compressed air | 0.3 m3/min 0.3 Mpa |
| Vacuum suction | 3.0 m3/min -0.014 Mpa |
| Outline dimensions(Mm) | 740 x 510 x 1500 |
| Product Weight(Kilograms) | 80 |
1.Nomally shipping steps:
2.Our packing and shipping:
Pre-Sales Service:
* Inquiry and consulting support.
*Quickly reaction.
*Factory inspection available anytime.
After-Sales Service:
*Prompt technical support
*Engineers available to service machinery overseas
*Installation &commissioning,good training for customers.
Q1.What's your delivery method?
A1:We commonly use sea transportation, using container to deliver the goods through Shanghai Port.
Q2.What products can you provide?
A2:Our main product includes powder mixers,granulating equipments,drying equipments,capsule fillers,blister packing machines,tablet/capsule counting filling line,ampoule/vial/oral liquid filling line includes ultrasonic washing machine,sterilization oven,filling capping machine,labeling machine.
Q3. What’s the payment terms?
A3:We will confirm the payment with you when quoting, like FCA, CIF or others.T/T is the main payment, and D/P is acceptable as well.
Q4.How do you ensure your product quality?
A4:We conduct inspections in every production procedure, and for finished products, we will take 100% inspection depend on international standards according to customer's requirements.
Q5:Does the machine power voltage meet buyers' factory power source?
A5: We can do it as your request.
Q6: Is it difficult to install the machine ?
A6: For standard small machines, the machines will be packed with no take apart, it comes to you to be a complete machine; you just need to connect power and compressed air to machine, then begin to operate the machine.
For large size machines, we will take the machine apart, on condition that we do our best to keep the machine easy to assembly.
You will get videos and instructions about installation of machine from us.
