Semi-Automatic Capsule Filling Machine Filler
Machine characteristics
1. This machine is a semi-automatic capsule filling equipment that integrates machine, electricity, and gas. It can independently complete actions such as seeding, separation, powder filling, and locking. It is easy to operate and accurate to fill. The body and workbench are made of stainless steel, which meets the hygiene requirements of the pharmaceutical industry. It is suitable for capsule filling in powder, granular form, or other products.
2. The seeding bag, feeding propeller, and filling turntable all adopt variable frequency speed regulation and operate automatically after setting.
3. The machine has low requirements for capsules and a high usage rate.
4. The traditional gearbox has been eliminated, with a simplified and compact structure and convenient operation and maintenance.
Introduction
CGN-208D new semi-automatic Capsule Filling Machine is new medical packing machinery with novel structure and artistic molding. It adopts mini computer speed-adjusting equipment, and to be controlled by the electric and pneumatic, equips electron automatic counting device. It can respectively finish the different processes separately such as arrangement, separating, filling, locking and etc. Which reduce labor intensity, improve production efficiency, raise the accuracy of filling dosage. The machine meet with GMP standard.
This product is composed of sending capsule, arranging capsule and separation mechanism, medicines filling mechanism, tight locking mechanism, mini computer speed-adjusting mechanism, pneumatic and electric control system, protective equipment, vacuum pump, air pump accessories etc. It is suitable for both the domestic and imported capsules; Certificated rate is more than 97%.
| Maximum productive capacity | 15000pcs/h |
| Capsule size | 00#, 0#, 1#, 2#, 3#, 4# hard capsule |
| Power (kw) | 2.2 |
| Power supply | 380V 50Hz |
| Ovrerall dimensions (mm) | 1350x700x1600(LxWxH) |
| Weight (kg) | 400 |
![KE1PX$_SO]LLORZU3`DH8UW](http://img.yfisher.com/m5591/1716955263299568.png)
![RX2]L7{%NOW0`YXF9~)M{_G](http://img.yfisher.com/m5591/171695526519cd71.png)
