Vacuum Belt Dryer for Liquid &Paste
Product Description
The vacuum belt continuous dryer for liquid is designed to solve the problems associated with extracting highly concentrated materials in viscous products.
Traditionally, a centrifugal spray dryer would damage the thermally sensitive components and lead to materials sticking to the walls of the dryer. Also, regular vacuum ovens are not ideal for these types of operations because the ovens take long periods of time for drying and require large amounts of energy.
This tray dryer is ideal because it features a low drying temperature with excellent sanitary features and it can fully meet GMP requirements.
| NO | NAME | TECHNICAL DATA |
| 1 | Drying area | ≥32.4m²(Heating area ≥30m²; cooling area ≥2.4.m²) |
| 2 | Number of layers | 3 layers; belt width 1100mm |
| 3 | Drying cabin size | Ø1600mm×12000mm×3000mm(dryer inner diameter×length× height) |
| 4 | Vacuum degree | 1100Pa~3300Pa (digital display index: -97~-99KPa) can be adjusted online during dynamic drying |
| 5 | Water evaporation | 25-30 kg per hour (depending on material characteristics) |
| 6 | Power | 45KW (slightly different depending on the configuration); normally open 40KW |
| 7 | Heating method | Hot water ( must be use Deionized water which chloride ion below 22.3mg/L) |
8 | Heating temperature | First paragraph: 35 ~ 130 ºC (adjustable) Second paragraph: 35 ~ 130 ºC (adjustable) The third paragraph: 35 ~ 130 ºC (adjustable) Fourth paragraph: 20 ~ 35 ºC (adjustable) * cooling water |
| 9 | Operational form | Automatic operation + manual operation |
| 10 | Cooling water consumption | 8~12T/h; temperature 25~30°C (user-supplied circulating cooling water system) |
| 11 | Drying cabin dimension | 13000 (including the distance when the two doors are opened) × 1700 × 3500 / mm (length × width × height) |
| 12 | Auxiliary machine dimension | 11000×2000×4000/mm (length×width×height) |
| 13 | Cleaning method | CIP totally automatic (or manual) in-place cleaning |
| 14 | Belt correction mode | totally automatic mechanical timing limit correction |
| 15 | Belt transfer speed | 100~1300mm/min(frequency control) |
| 16 | Net distance between belts | Not less than 160mm |
| 17 | Feed rate | 15L-150L/h(frequency control) |
| 18 | Discharge form | Spiral output + vacuum breaking |
| 19 | Operating Voltage | 380V (three-phase five-wire system) |
| 20 | Compressed air | 0.5 to 0.7 MPa (user-supplied) |
| 21 | Weight | Dryer 11000Kg;auxiliary machine 5500Kg |
1.Nomally shipping steps:
2.Our packing and shipping:
![(4[KDGL_NF%E6%2]D`4JYP](http://sc02.alicdn.com/kf/HTB1yfSOaQT2gK0jSZFk763IQFXaB/224767400/HTB1yfSOaQT2gK0jSZFk763IQFXaB.png)
![0OC}YRDYXP])TO]QMXZ48IJ](http://sc01.alicdn.com/kf/HTB1txKNaUH1gK0jSZSy760tlpXaM/224767400/HTB1txKNaUH1gK0jSZSy760tlpXaM.png)
Pre-Sales Service:
* Inquiry and consulting support.
*Quickly reaction.
*Factory inspection available anytime.
After-Sales Service:
*Prompt technical support
*Engineers available to service machinery overseas
*Installation &commissioning,good training for customers.
![KE1PX$_SO]LLORZU3`DH8UW](http://sc02.alicdn.com/kf/HTB1FuKPaQH0gK0jSZPi761vapXaz/224767400/HTB1FuKPaQH0gK0jSZPi761vapXaz.png)
![RX2]L7{%NOW0`YXF9~)M{_G](http://sc02.alicdn.com/kf/HTB1UHmNaQP2gK0jSZPx761cQpXa8/224767400/HTB1UHmNaQP2gK0jSZPx761cQpXa8.png)
Q1.What's your delivery method?
A1:We commonly use sea transportation, using container to deliver the goods through Shanghai Port.
Q2.What products can you provide?
A2:Our main product includes powder mixers,granulating equipments,drying equipments,capsule fillers,blister packing machines,tablet/capsule counting filling line,ampoule/vial/oral liquid filling line includes ultrasonic washing machine,sterilization oven,filling capping machine,labeling machine.
Q3. What's the payment terms?
A3:We will confirm the payment with you when quoting, like FCA, CIF or others.T/T is the main payment.
Q4.How do you ensure your product quality?
A4:We conduct inspections in every production procedure, and for finished products, we will take 100% inspection depend on international standards according to customer's requirements.
Q5:Does the machine power voltage meet buyers' factory power source?
A5: We can do it as your request.
Q6: Is it difficult to install the machine ?
A6: For standard small machines, the machines will be packed with no take apart, it comes to you to be a complete machine; you just need to connect power and compressed air to machine, then begin to operate the machine.
For large size machines, we will take the machine apart, on condition that we do our best to keep the machine easy to assembly.
You will get videos and instructions about installation of machine from us.
