BY Series Simple film coating machine
Features:
1. The coating machine has convenient feeding and high efficiency.
2. Easy to clean, the coating pot can be disassembled on its own.
3. The coating machine adopts an imported spray gun, which is easy to operate and control, with flexible control of process requirements, good atomization effect, and uniform spraying of medication.
4. The half hole design and pot body design of this machine help reduce wear on the chip and coating film, improve the yield, and thus balance drying efficiency and protection of the coating film.
5. This machine can be equipped with 1-2 different specifications of pots according to needs, to solve the confusion of a large variety, small quantity, and high raw material prices in the laboratory. The interchangeable pot body can better adapt to diverse customer needs.
Function:
Within the same device, the following functions can be completed without replacing any device components: powder, granules, pellets, crystals, capsules, tablets, seed coating, powder granulation, pelletizing, polishing, and mixing.
Powder, granules, pellets, crystals, capsules, tablets, seed coating: This machine has a good coating effect and uniform coating.
Powder granulation and pill making: By rotating the coating pot, powder can be made into granules or pills.
Drying: It has a good drying effect on newly made pills.
Polishing: Can polish the surface of pills.
Mixing: can mix two or more powders and particles.
Application:
It is used to coat tablets and pills with sugar in pharmaceutical and food Industry.
These machines sugarcoat the tablets and pills for pharmaceutical and food industries. It is also used for rolling and heating beans and edible nuts or seeds. As its feature, the sugarcoating round pot is elevated with a elevation 30° To the horizontal, the heater such as gas or electrical heater can placed directly under the pot. A separated blower with electric heater is provided with the machine. The pipe of the blower stretches into the pot for heating or cooling purpose. The thermal capacity can be selected in two levels.
| Type | Capacity (Kg) | Angle of inclination | Motor power (Kw) | Fan power (Kw) | Overall dimension (mm) | Heating power (Kw) | Weight (Kg) | Rotary speed (rad/min) |
| BY300 | 1~3 | 30° | 0.37 | 40 | 800×800×1200 | 1KW | 200KG | 0-46 |
| BY400 | 2~5 | 30° | 0.55 | 40 | 800×800×1200 | 1KW | 200KG | 0-46 |
| BY800 | 30~50 | 30° | 1.1 | 200 | 1000×1000×1550 | 3KW | 400KG | 0-32 |
| BY1000 | 50~70 | 30° | 1.5 | 200 | 1200×1200×1600 | 4KW | 450KG | 0-32 |
| BY1250 | 80~150 | 30° | 2.2 | 370 | 1350×1350×1600 | 6kw | 800KG | 0-28 |
