dry rolling granulator
Working principle of dry rolling granulator: Dry powder material is added from the top of the equipment, and after degassing and spiral preloading, it enters the counter roll. Under the tremendous squeezing force of the counter roll, the material undergoes plastic deformation and is compressed into flakes. The sheet-like material undergoes processes such as crushing, granulation, and screening to obtain granular products.
feature
1. The material is mechanically compressed and formed without adding any wetting agent, ensuring the purity of the product.
2. The process flow is short, the energy consumption is low, and there are few auxiliary equipment and personnel configurations.
3. The dry powder is directly granulated without the need for subsequent drying processes.
4. The particle strength is high, and the increase in bulk density is more significant than other granulation methods.
5. The operation has great flexibility and a wide range of adaptability, and the particle strength can be adjusted by hydraulic pressure.
6. Closed loop operation of the system to achieve continuous production
Scope of application
fertilizer
Potassium sulfate, potassium chloride, Russian red potassium, potassium nitrate, ammonium chloride, monoammonium phosphate, diammonium phosphate, NPK compound fertilizer, imported Russian potassium sulfate, phosphate powder, sulfuric acid saddle, calcium superphosphate, humic acid, etc.
powder material
Zinc oxide, desulfurization gypsum, lead oxide, calcium chloride, calcium phosphate, bleaching powder, cryolite, antioxidant, white carbon black, benzodiazepine, etc
The equipment consists of a pre feeder, a rolling mill, a granulator, and other components. It adopts hydraulic driven double roll counter extrusion forming technology, and the surface of the rolling mill is equipped with holes to improve compression efficiency. Equipped with a variable frequency speed control motor and PLC automation control system, it can adjust pressure, feeding speed, and particle strength, and has the characteristics of continuous production, low energy consumption, and compact structure. Equipment materials are mostly made of stainless steel and alloys to enhance wear and corrosion resistance. Some models are equipped with water cooling devices, screening and dust removal functions, and intelligent operation modes
It is suitable for the preparation of chemical materials such as ammonium sulfate and compound fertilizers, as well as pharmaceutical tablet granules and capsule filling granules, especially for the granulation needs of powders that are sensitive to humidity or heat. Some manufacturers provide customized solutions to support applications in special fields such as refractory materials
Prelated parameters
| No | name | model and specification | material | quantity |
| 1 | bucket elevator | HL160 3.0kw | Q235 carbon steel | 1 set |
| 2 | transition silo | Φ800mm, Volume 0.4m3 Equipped with a 0.05kw vibration motor | Q235 carbon steel | 1 set |
| 3 | Quantitative spiral feeding screw | Φ159mm 1.5kw variable frequency speed regulation | Twisted Dragon Blade 304 Stainless Steel/ Other Q235 carbon steel | 1 set |
| 4 | Cone spiral forced feeder | 5.5kw with variable frequency speed regulation | Vertical winch 304 stainless steel/ Other Q235 carbon steel | 1 set |
| 5 | Roller press main machine | Roll diameter Φ 360mm Roll width 180mm 30kw main motor Equipped with a 0.75kw electric hydraulic system | The rolling mill is made of alloy steel/ Other Q235 carbon steel | 1 set |
| 6 | crusher | 4.0kw cross blade structure | The crushing blade is made of manganese steel/ Other Q235 carbon steel | 1 set |
| 7 | Whole grain machine | 7.5kw cross blade structure | The whole blade is made of manganese steel/ Other Q235 carbon steel | 1 set |
| 8 | Three element rotary vibrating screen | Ф1500mm 2.2kw | Q235 carbon steel | 1 set |
| 9 | control cabinet | enterprise standard (including 2 frequency converters) | Q235 spray coating/component | 1 set |
