    The latest designed effervescent tablet tube filler is more lower and compact design with acrylic cover for protection


    Detailed Product Description
    A Tube Filling Machine For Tablet is applicable to the packing bigger and thinner tablets which are orderly fed into bobbin bottles in single row in an overlapping way.
    This unit is safe, efficient, accurate and clean. It sells well with its high quality and performance.
    This unit was designed for layered filling of tablets into a tube and then placing a plastic stopper in the top.

    Feature of automatic tube feeder.

    Automatic tablet channel Counting. 100% accurate.
    No tube, no filling; No tablets, no capping.
    Automatic vibratory bowl for stopper (cap feeding).
    Automatic cap press sealing.

    Model ZPP-40A
    Filling range 10-30tablets/tube as per customer's requirement
    Diameter of tablet 12-30mm
    Thickness of Tablet 3-8mm
    Length of Tube 80-180mm
    Max.Capacity 40Tubes/min depending on the product and tube size
    Power supply 0.8kw
    Compressive air 0.5~0.7MPa,0.28m3/min
    Overall size 2000mm*1600mm*1680mm
    Weight 600Kgs

    Effervescent Tablet Tube Filling Machine


    Packaging & Shipping

     1.Nomally shipping steps:

     S45PNZ%`OL`M6O8H}V(SDJ

    2.Our packing and shipping:

    (4[KDGL_NF%E6%2]D`4JYP

    Our Services

     0OC}YRDYXP])TO]QMXZ48IJ

         Pre-Sales Service:



             * Inquiry and consulting support.



             *Quickly reaction.



              *Factory inspection available anytime.





          After-Sales Service:



             *Prompt technical support



            *Engineers available to service machinery overseas



            *Installation &commissioning,good training for customers.





    Our customer

     KE1PX$_SO]LLORZU3`DH8UW



    Certifications

    [$X~Z{0)[{$PW5F}H666N6M



    Company Information

    RX2]L7{%NOW0`YXF9~)M{_G



    FAQ

     Q1.What's your delivery method?

     A1:We commonly use sea transportation, using container to deliver the goods through Shanghai Port.



    Q2.What products can you provide?

    A2:Our main product includes powder mixers,granulating equipments,drying equipments,capsule fillers,blister packing machines,tablet/capsule counting filling line,ampoule/vial/oral liquid filling line includes ultrasonic washing machine,sterilization oven,filling capping machine,labeling machine.



    Q3. What's the payment terms?

    A3:We will confirm the payment with you when quoting, like FCA, CIF or others.T/T is the main payment.



    Q4.How do you ensure your product quality?

    A4:We conduct inspections in every production procedure, and for finished products, we will take 100% inspection depend on international standards according to customer's requirements.



    Q5:Does the machine power voltage meet buyers' factory power source?

    A5: We can do it as your request.



    Q6: Is it difficult to install the machine ?

    A6: For standard small machines, the machines will be packed with no take apart, it comes to you to be a complete machine; you just need to connect power and compressed air to machine, then begin to operate the machine.

    For large size machines, we will take the machine apart, on condition that we do our best to keep the machine easy to assembly.

    You will get videos and instructions about installation of machine from us.
