vacuum emulsifying mixer for alcohol gel

Quantity:

vacuum emulsifying mixer for alcohol gel


USE:

This series of products are specially designed high-efficiency emulsifying pots according to the requirements of mass production. The products have the advantages of large output, low energy consumption, strong adaptability and wide versatility. They are mainly suitable for liquid detergents (such as detergent, shampoo, The preparation of shower gel, laundry detergent, etc.) is the ideal equipment for the production of gel products. There are many types of liquid washing equipment, which can be configured according to the user's production site space and process requirements.

1. The rotating speed of the homogenizer is 3000 rpm, and the rotating speed of the scraping wall is 60 rpm. Frequency

2. The inner pot of the emulsified stirring pot is made of SUS316L stainless steel,

3. The stirring type has a tower multi-layer stirring blade. For high viscosity, a high-speed dispersing stirrer can be equipped.

4. Automatic control. The operation is simple and convenient. The emulsifier and paddle stirring can be used separately or at the same time.


Feature:
1. The material of contacted part is SUS316L stainless steel, inside and outside of the equipment are with mirror polishing and get to GMP standard.

2. All pipelines and parameter are controlled automaticlly. And the electric appliance which are imported from foreign country, like Siemens, Schneider and so on.

3. Emulsifying tank is with CIP cleaning system, it make the cleaning to be easy and effective.

4. Emulsifying tank adopts tertiary agitating system, and during the emulsification, the whole processing is under a vacuum environment, so it not only can eliminate spume which created in the emulsification processing, but also can avoid the unnecessary pollution.


Model

Volume

Emulsify

mixer

Outside dimension  (mm)

Kw

r/min

Kw

r/min

L

W

H

M H

TZZRJ- 5

5 L

0.75

0- 100 00

0. 5

0-70

1 1 00

800

1 1 00

1 50 0

TZZRJ-30

30L

1.5

0-3500

0.75

0-70

1500

800

1500

2050

TZZRJ-50

50L

3

0-3500

0.75

0-70

2750

2100

1900

2600

TZZRJ-100

100L

3

0-3500

1.5

0-70

2800

2150

2100

2800

TZZRJ-150

150L

4

0-3500

1.5

0-70

2850

2150

2150

2900

TZZRJ-200

200L

4

0-3500

1.5

0-70

3000

2200

2200

3100

TZZRJ-350

350L

5.5

0-3500

2.2

0-70

3650

2650

2550

3600

TZZRJ-500

500L

7.5

0-3500

2.2

0-50

3800

2800

2700

3950

TZZRJ-750

750L

11

0-3500

3.7

0-50

3900

3900

2900

4400

TZZRJ-1000

1000L

11

0-3500

3.7

0-50

3900

3400

3150

4550

TZZRJ-2000

2000L

22

0-3500

7.5

0-50

4850

4300



Pictures:
13

14





Packaging & Shipping

 1.Nomally shipping steps:

 S45PNZ%`OL`M6O8H}V(SDJ

2.Our packing and shipping:

(4[KDGL_NF%E6%2]D`4JYP

Our Services

 0OC}YRDYXP])TO]QMXZ48IJ

     Pre-Sales Service:



         * Inquiry and consulting support.



         *Quickly reaction.



          *Factory inspection available anytime.





      After-Sales Service:



         *Prompt technical support



        *Engineers available to service machinery overseas



        *Installation &commissioning,good training for customers.





Our customer

 KE1PX$_SO]LLORZU3`DH8UW



Certifications

[$X~Z{0)[{$PW5F}H666N6M



Company Information

RX2]L7{%NOW0`YXF9~)M{_G



FAQ

 Q1.What's your delivery method?

 A1:We commonly use sea transportation, using container to deliver the goods through Shanghai Port.



Q2.What products can you provide?

A2:Our main product includes powder mixers,granulating equipments,drying equipments,capsule fillers,blister packing machines,tablet/capsule counting filling line,ampoule/vial/oral liquid filling line includes ultrasonic washing machine,sterilization oven,filling capping machine,labeling machine.



Q3. What's the payment terms?

A3:We will confirm the payment with you when quoting, like FCA, CIF or others.T/T is the main payment.



Q4.How do you ensure your product quality?

A4:We conduct inspections in every production procedure, and for finished products, we will take 100% inspection depend on international standards according to customer's requirements.



Q5:Does the machine power voltage meet buyers' factory power source?

A5: We can do it as your request.



Q6: Is it difficult to install the machine ?

A6: For standard small machines, the machines will be packed with no take apart, it comes to you to be a complete machine; you just need to connect power and compressed air to machine, then begin to operate the machine.

For large size machines, we will take the machine apart, on condition that we do our best to keep the machine easy to assembly.

You will get videos and instructions about installation of machine from us.
